UCC5310MCDWV

In Stock: 7,825
UCC5310MCDWV - Texas Instruments - Isolators - Gate Drivers
REF: UCC5310MCDWV Texas Instruments
UCC5310MCDWV

Texas Instruments

2A /1A 5KVRMS ISOGATE DR-MILLER

UCC5310MCDWV is a Isolators - Gate Drivers manufactured by Texas Instruments. 2A /1A 5KVRMS ISOGATE DR-MILLER. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case 8-SOIC (0.295", 7.50mm Width), approval agency CQC, UR, VDE.

Datasheet Request a Quote

In Stock: 7,825

Specifications

18 parameters
Product StatusActive
TechnologyCapacitive Coupling
Number of Channels1
Voltage - Isolation3000Vrms
Common Mode Transient Immunity (Min)100kV/µs
Propagation Delay tpLH / tpHL (Max)75ns, 75ns
Pulse Width Distortion (Max)20ns
Rise / Fall Time (Typ)12ns, 10ns
Current - Output High, Low2.4A, 1.1A
Current - Peak Output4.3A
Voltage - Forward (Vf) (Typ)-
Current - DC Forward (If) (Max)-
Voltage - Output Supply13.2V ~ 33V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case8-SOIC (0.295", 7.50mm Width)
Supplier Device Package8-SOIC
Approval AgencyCQC, UR, VDE
