UCC23511QDWYRQ1

In Stock: 850
UCC23511QDWYRQ1 - Texas Instruments - Isolators - Gate Drivers
REF: UCC23511QDWYRQ1 Texas Instruments
UCC23511QDWYRQ1

Texas Instruments

AUTOMOTIVE 1.5-A SOURCE, 2-A SIN

UCC23511QDWYRQ1 is a Isolators - Gate Drivers manufactured by Texas Instruments. AUTOMOTIVE 1.5-A SOURCE, 2-A SIN. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - forward (vf) (typ) 2.1V, package / case 6-SOIC (0.295", 7.50mm Width).

Request a Quote

In Stock: 850

Tiered Pricing USD
1+ $2.3800 —
10+ $1.7640 -26%
25+ $1.6108 -32%
100+ $1.4422 -39%
250+ $1.3619 -43% BEST

Specifications

18 parameters
Product StatusActive
TechnologyCapacitive Coupling
Number of Channels1
Voltage - Isolation5700Vrms
Common Mode Transient Immunity (Min)150kV/µs
Propagation Delay tpLH / tpHL (Max)105ns, 105ns
Pulse Width Distortion (Max)35ns
Rise / Fall Time (Typ)28ns, 25ns (Max)
Current - Output High, Low1A, 1A
Current - Peak Output1.5A, 2A
Voltage - Forward (Vf) (Typ)2.1V
Current - DC Forward (If) (Max)25 mA
Voltage - Output Supply14V ~ 33V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case6-SOIC (0.295", 7.50mm Width)
Supplier Device Package6-SOIC
Approval AgencyCQC, UL, VDE
