UCC23313BDWYR

In Stock: 1,289
UCC23313BDWYR - Texas Instruments - Isolators - Gate Drivers
REF: UCC23313BDWYR Texas Instruments
UCC23313BDWYR

Texas Instruments

4-A, 3.75-KVRMS OPTO-COMPATIBLE

UCC23313BDWYR is a Isolators - Gate Drivers manufactured by Texas Instruments. 4-A, 3.75-KVRMS OPTO-COMPATIBLE. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - forward (vf) (typ) 2.1V, package / case 6-SOIC (0.295", 7.50mm Width).

Request a Quote

In Stock: 1,289

Tiered Pricing USD
1+ $0.7800 —
10+ $0.5560 -29%
25+ $0.4996 -36%
100+ $0.4381 -44%
250+ $0.4087 -48% BEST

Specifications

18 parameters
Product StatusActive
TechnologyOptical Coupling
Number of Channels1
Voltage - Isolation3750Vrms
Common Mode Transient Immunity (Min)150kV/µs
Propagation Delay tpLH / tpHL (Max)105ns, 105ns
Pulse Width Distortion (Max)35ns
Rise / Fall Time (Typ)28ns, 25ns (Max)
Current - Output High, Low4.5A, 5.3A
Current - Peak Output4.5A, 5.3A
Voltage - Forward (Vf) (Typ)2.1V
Current - DC Forward (If) (Max)16 mA
Voltage - Output Supply14V ~ 33V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case6-SOIC (0.295", 7.50mm Width)
Supplier Device Package6-SOIC
Approval AgencyCQC, UL, VDE
