Name: UC3178QPTR
Brand: Texas Instruments
SKU: UC3178QPTR
Price: 3.93 USD
Availability: InStock

REF: UC3178QPTR Texas Instruments

UC3178QPTR

IC POWER 2 CIRCUIT 28PLCC

UC3178QPTR is a Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps manufactured by Texas Instruments. IC POWER 2 CIRCUIT 28PLCC. Key specifications: mounting type Surface Mount, operating temperature 0°C ~ 70°C, package / case 28-LCC (J-Lead), current - supply 13mA (x2 Channels).

Datasheet Request a Quote

In Stock: 12,000

Specifications

17 parameters

Product Status	Obsolete
Amplifier Type	Power
Number of Circuits	2
Output Type	-
Slew Rate	1V/µs
Gain Bandwidth Product	2 MHz
-3db Bandwidth	-
Current - Input Bias	50 µA
Voltage - Input Offset	12 mV

Current - Supply	13mA (x2 Channels)
Current - Output / Channel	450 mA
Voltage - Supply Span (Min)	3 V
Voltage - Supply Span (Max)	15 V
Operating Temperature	0°C ~ 70°C
Mounting Type	Surface Mount
Package / Case	28-LCC (J-Lead)
Supplier Device Package	28-PLCC (11.51x11.51)
