LM309K STEEL/NOPB

In Stock: 7,913
LM309K STEEL/NOPB - Texas Instruments - PMIC - Voltage Regulators - Linear
REF: LM309K STEEL/NOPB Texas Instruments
LM309K STEEL/NOPB

Texas Instruments

IC REG LINEAR 5.05V 1.5A TO3-2

LM309K STEEL/NOPB is a PMIC - Voltage Regulators - Linear manufactured by Texas Instruments. IC REG LINEAR 5.05V 1.5A TO3-2. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 125°C, package / case TO-204AA, TO-3, current - supply (max) 10 mA.

Datasheet Request a Quote

In Stock: 7,913

Tiered Pricing USD
1+ $97.2300 —
10+ $81.3560 -16%
50+ $75.0042 -23%
100+ $73.0383 -25% BEST

Specifications

18 parameters
Product StatusActive
Output ConfigurationPositive
Output TypeFixed
Number of Regulators1
Voltage - Input (Max)25V
Voltage - Output (Min/Fixed)5.05V
Voltage - Output (Max)-
Voltage Dropout (Max)-
Current - Output1.5A
Current - Quiescent (Iq)5.2 mA
Current - Supply (Max)10 mA
PSRR-
Control Features-
Protection FeaturesOver Temperature
Operating Temperature0°C ~ 125°C
Mounting TypeThrough Hole
Package / CaseTO-204AA, TO-3
Supplier Device PackageTO-3-2
