LM109K

In Stock: 9,771
LM109K - Texas Instruments - PMIC - Voltage Regulators - Linear
REF: LM109K Texas Instruments
LM109K

Texas Instruments

IC REG LINEAR 5.05V 1A TO3-2

LM109K is a PMIC - Voltage Regulators - Linear manufactured by Texas Instruments. IC REG LINEAR 5.05V 1A TO3-2. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 150°C, package / case TO-204AA, TO-3, current - supply (max) 10 mA.

Datasheet Request a Quote

In Stock: 9,771

Specifications

18 parameters
Product StatusActive
Output ConfigurationPositive
Output TypeFixed
Number of Regulators1
Voltage - Input (Max)25V
Voltage - Output (Min/Fixed)5.05V
Voltage - Output (Max)-
Voltage Dropout (Max)-
Current - Output1A
Current - Quiescent (Iq)5.2 mA
Current - Supply (Max)10 mA
PSRR-
Control Features-
Protection FeaturesOver Current, Over Temperature
Operating Temperature-55°C ~ 150°C
Mounting TypeThrough Hole
Package / CaseTO-204AA, TO-3
Supplier Device PackageTO-3-2
