DAC811AH

In Stock: 1,287
DAC811AH - Texas Instruments - Data Acquisition - Digital to Analog Converters (DAC)
REF: DAC811AH Texas Instruments
DAC811AH

Texas Instruments

IC DAC 12BIT V-OUT 28CDIP

DAC811AH is a Data Acquisition - Digital to Analog Converters (DAC) manufactured by Texas Instruments. IC DAC 12BIT V-OUT 28CDIP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C, voltage - supply, digital 5V, package / case 28-CDIP (0.600", 15.24mm) Window.

Datasheet Request a Quote

In Stock: 1,287

Specifications

16 parameters
Product StatusObsolete
Number of Bits12
Number of D/A Converters1
Settling Time4µs
Output TypeVoltage - Buffered
Differential OutputNo
Data InterfaceParallel
Reference TypeInternal
Voltage - Supply, Analog±11.4V ~ 16.5V
Voltage - Supply, Digital5V
INL/DNL (LSB)±0.25, ±0.5
ArchitectureR-2R
Operating Temperature-25°C ~ 85°C
Package / Case28-CDIP (0.600", 15.24mm) Window
Supplier Device Package28-CDIP
Mounting TypeThrough Hole
