TEA2261

In Stock: 5,290
TEA2261 - STMicroelectronics - PMIC - AC DC Converters, Offline Switchers
REF: TEA2261 STMicroelectronics
TEA2261

STMicroelectronics

IC OFFLINE SWITCH 16DIP

TEA2261 is a PMIC - AC DC Converters, Offline Switchers manufactured by STMicroelectronics. IC OFFLINE SWITCH 16DIP. Key specifications: mounting type Through Hole, operating temperature -20°C ~ 70°C (TA), voltage - supply (vcc/vdd) 7.4V ~ 20V, package / case 16-DIP (0.300", 7.62mm).

Request a Quote

In Stock: 5,290

Specifications

16 parameters
Product StatusObsolete
Output IsolationIsolated
Internal Switch(s)No
Voltage - Breakdown-
Topology-
Voltage - Start Up10.3 V
Voltage - Supply (Vcc/Vdd)7.4V ~ 20V
Duty Cycle60%
Frequency - Switching10kHz ~ 100kHz
Power (Watts)140 W
Fault ProtectionCurrent Limiting, Over Voltage
Control FeaturesSoft Start
Operating Temperature-20°C ~ 70°C (TA)
Package / Case16-DIP (0.300", 7.62mm)
Supplier Device Package16-DIP
Mounting TypeThrough Hole
