Name: STGB7NB60KDT4
Brand: STMicroelectronics
SKU: STGB7NB60KDT4
Availability: InStock

REF: STGB7NB60KDT4 STMicroelectronics

STGB7NB60KDT4

IGBT 600V 14A 80W D2PAK

STGB7NB60KDT4 is a Transistors - IGBTs - Single manufactured by STMicroelectronics. IGBT 600V 14A 80W D2PAK. Key specifications: mounting type Surface Mount, operating temperature 150°C (TJ), package / case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB, current - collector (ic) (max) 14 A.

Datasheet Request a Quote

In Stock: 4,646

Specifications

17 parameters

Product Status	Obsolete
IGBT Type	-
Voltage - Collector Emitter Breakdown (Max)	600 V
Current - Collector (Ic) (Max)	14 A
Current - Collector Pulsed (Icm)	56 A
Vce(on) (Max) @ Vge, Ic	2.8V @ 15V, 7A
Power - Max	80 W
Switching Energy	140µJ (off)
Input Type	Standard

Gate Charge	32.7 nC
Td (on/off) @ 25°C	15ns/50ns
Test Condition	480V, 7A, 10Ohm, 15V
Reverse Recovery Time (trr)	50 ns
Operating Temperature	150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package	D2PAK
