Name: MASTERGAN4
Brand: STMicroelectronics
SKU: MASTERGAN4
Price: 12.21 USD
Availability: InStock

REF: MASTERGAN4 STMicroelectronics

MASTERGAN4

HIGH POWER DENSITY 600V HALF BRI

MASTERGAN4 is a PMIC - Full, Half-Bridge Drivers manufactured by STMicroelectronics. HIGH POWER DENSITY 600V HALF BRI. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 3.3V ~ 15V, package / case 31-VQFN Exposed Pad.

Datasheet Request a Quote

In Stock: 10

Tiered Pricing USD

1+ $12.2100 —

10+ $9.5910 -21%

25+ $8.9364 -27%

100+ $8.2165 -33%

260+ $7.8605 -36%

520+ $7.6560 -37%

1,040+ $7.4876 -39% BEST

Specifications

17 parameters

Product Status	Active
Output Configuration	Half Bridge
Applications	General Purpose
Interface	Logic
Load Type	Capacitive and Resistive
Technology	-
Rds On (Typ)	225mOhm LS, 225mOhm HS
Current - Output / Channel	6.5A
Current - Peak Output	6.5A

Voltage - Supply	3.3V ~ 15V
Voltage - Load	3.3V ~ 15V
Operating Temperature	-40°C ~ 125°C
Features	Bootstrap Circuit
Fault Protection	Over Temperature, UVLO
Mounting Type	Surface Mount
Package / Case	31-VQFN Exposed Pad
Supplier Device Package	31-QFN (9x9)
