Name: MASTERGAN3TR
Brand: STMicroelectronics
SKU: MASTERGAN3TR
Price: 7.48 USD
Availability: InStock

REF: MASTERGAN3TR STMicroelectronics

MASTERGAN3TR

STMicroelectronics

HIGH POWER DENSITY 600 V HALF BR

MASTERGAN3TR is a PMIC - Full, Half-Bridge Drivers manufactured by STMicroelectronics. HIGH POWER DENSITY 600 V HALF BR. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 3.3V ~ 15V, package / case 31-VQFN Exposed Pad.

Datasheet Request a Quote

In Stock: 488

Tiered Pricing USD

1+ $7.4800 —

10+ $5.7770 -23%

25+ $5.3524 -28%

100+ $4.8849 -35%

250+ $4.6621 -38%

500+ $4.5278 -39%

1,000+ $4.4173 -41% BEST

Specifications

17 parameters

Product Status	Active
Output Configuration	Half Bridge
Applications	DC-DC Converters
Interface	Logic
Load Type	Inductive, Capacitive, Resistive
Technology	DMOS
Rds On (Typ)	225mOhm LS, 450mOhm HS
Current - Output / Channel	6.5A, 4A
Current - Peak Output	6.5A, 4A

Voltage - Supply	3.3V ~ 15V
Voltage - Load	3.3V ~ 15V
Operating Temperature	-40°C ~ 125°C
Features	Bootstrap Circuit
Fault Protection	Over Temperature, UVLO
Mounting Type	Surface Mount
Package / Case	31-VQFN Exposed Pad
Supplier Device Package	31-QFN (9x9)
