LF120ABV

In Stock: 6,385
LF120ABV - STMicroelectronics - PMIC - Voltage Regulators - Linear
REF: LF120ABV STMicroelectronics
LF120ABV

STMicroelectronics

IC REG LIN 12V 500MA 5PENTAWATT

LF120ABV is a PMIC - Voltage Regulators - Linear manufactured by STMicroelectronics. IC REG LIN 12V 500MA 5PENTAWATT. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 125°C, package / case Pentawatt-5 (Vertical, Bent and Staggered Leads), current - supply (max) 12 mA.

Datasheet Request a Quote

In Stock: 6,385

Specifications

18 parameters
Product StatusObsolete
Output ConfigurationPositive
Output TypeFixed
Number of Regulators1
Voltage - Input (Max)16V
Voltage - Output (Min/Fixed)12V
Voltage - Output (Max)-
Voltage Dropout (Max)0.7V @ 500mA
Current - Output500mA
Current - Quiescent (Iq)1.5 mA
Current - Supply (Max)12 mA
PSRR69dB ~ 54dB (120Hz ~ 10kHz)
Control Features-
Protection FeaturesOver Current, Over Temperature
Operating Temperature-40°C ~ 125°C
Mounting TypeThrough Hole
Package / CasePentawatt-5 (Vertical, Bent and Staggered Leads)
Supplier Device Package5-PENTAWATT
