L4947

In Stock: 8,129
L4947 - STMicroelectronics - PMIC - Voltage Regulators - Linear
REF: L4947 STMicroelectronics
L4947

STMicroelectronics

IC REG LIN 5V 500MA 5PENTAWATT

L4947 is a PMIC - Voltage Regulators - Linear manufactured by STMicroelectronics. IC REG LIN 5V 500MA 5PENTAWATT. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 125°C, package / case Pentawatt-5 (Vertical, Bent and Staggered Leads), current - supply (max) 180 mA.

Datasheet Request a Quote

In Stock: 8,129

Specifications

18 parameters
Product StatusObsolete
Output ConfigurationPositive
Output TypeFixed
Number of Regulators1
Voltage - Input (Max)26V
Voltage - Output (Min/Fixed)5V
Voltage - Output (Max)-
Voltage Dropout (Max)0.75V @ 500mA
Current - Output500mA
Current - Quiescent (Iq)13 mA
Current - Supply (Max)180 mA
PSRR60dB (120Hz)
Control FeaturesReset
Protection FeaturesOver Temperature, Reverse Polarity, Short Circuit
Operating Temperature-40°C ~ 125°C
Mounting TypeThrough Hole
Package / CasePentawatt-5 (Vertical, Bent and Staggered Leads)
Supplier Device Package5-PENTAWATT
