PC942

In Stock: 7,361
PC942 - Sharp Microelectronics - Special Purpose
REF: PC942 Sharp Microelectronics
PC942

Sharp Microelectronics

OPTOISO 5KV OPIC 8DIP

PC942 is a Special Purpose manufactured by Sharp Microelectronics. OPTOISO 5KV OPIC 8DIP. Key specifications: mounting type Through Hole, operating temperature -20°C ~ 80°C, voltage - supply 5.4V ~ 13V, package / case 8-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 7,361

Specifications

17 parameters
Product StatusObsolete
TypePower Transistor Driver
Number of Channels1
Voltage - Isolation5000Vrms
Common Mode Transient Immunity (Min)10kV/µs
Input TypeDC
Current - Output / Channel500mA, 600mA
Propagation Delay tpLH / tpHL (Max)5µs, 5µs
Rise / Fall Time (Typ)200ns, 100ns
Voltage - Forward (Vf) (Typ)1.1 V
Current - DC Forward (If) (Max)25 mA
Voltage - Supply5.4V ~ 13V
Operating Temperature-20°C ~ 80°C
Mounting TypeThrough Hole
Package / Case8-DIP (0.300", 7.62mm)
Supplier Device Package8-DIP
Approval AgencyUR
