Name: PC6N139X
Brand: Sharp Microelectronics
SKU: PC6N139X
Availability: InStock

REF: PC6N139X Sharp Microelectronics

PC6N139X

OPTOISO 2.5KV DARL W/BASE 8-DIP

PC6N139X is a Optoisolators - Transistor, Photovoltaic Output manufactured by Sharp Microelectronics. OPTOISO 2.5KV DARL W/BASE 8-DIP. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 70°C, voltage - forward (vf) (typ) 1.5V, package / case 8-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 5,676

Specifications

18 parameters

Product Status	Obsolete
Number of Channels	1
Voltage - Isolation	2500Vrms
Current Transfer Ratio (Min)	400% @ 500µA
Current Transfer Ratio (Max)	-
Turn On / Turn Off Time (Typ)	300ns, 1.5µs
Rise / Fall Time (Typ)	-
Input Type	DC
Output Type	Darlington with Base

Voltage - Output (Max)	18V
Current - Output / Channel	60mA
Voltage - Forward (Vf) (Typ)	1.5V
Current - DC Forward (If) (Max)	20 mA
Vce Saturation (Max)	-
Operating Temperature	0°C ~ 70°C
Mounting Type	Through Hole
Package / Case	8-DIP (0.300", 7.62mm)
Supplier Device Package	8-DIP
