LV5761V-TLM-E

In Stock: 4,000
LV5761V-TLM-E - Sanyo - PMIC - Voltage Regulators - DC DC Switching Controllers
REF: LV5761V-TLM-E Sanyo
LV5761V-TLM-E

Sanyo

STEP-DOWN SWITCHING REGULATOR

LV5761V-TLM-E is a PMIC - Voltage Regulators - DC DC Switching Controllers manufactured by Sanyo. STEP-DOWN SWITCHING REGULATOR. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), voltage - supply (vcc/vdd) 8.5V ~ 42V, package / case 16-LSSOP (0.173", 4.40mm Width).

Datasheet Request a Quote

In Stock: 4,000

Specifications

18 parameters
Product StatusObsolete
Output TypeTransistor Driver
FunctionStep-Down
Output ConfigurationPositive
TopologyBuck
Number of Outputs1
Output Phases1
Voltage - Supply (Vcc/Vdd)8.5V ~ 42V
Frequency - Switching125kHz
Duty Cycle (Max)85%
Synchronous RectifierYes
Clock SyncYes
Serial Interfaces-
Control FeaturesCurrent Limit, Enable, Frequency Control, Soft Start
Operating Temperature-40°C ~ 85°C (TA)
Mounting TypeSurface Mount
Package / Case16-LSSOP (0.173", 4.40mm Width)
Supplier Device Package16-SSOP
