PS9332L-V-E3-AX

In Stock: 4,831
PS9332L-V-E3-AX - Renesas Electronics America Inc - Isolators - Gate Drivers
REF: PS9332L-V-E3-AX Renesas Electronics America Inc
PS9332L-V-E3-AX

Renesas Electronics America Inc

HI-SPD OPTOCPLR 6PIN SDIP

PS9332L-V-E3-AX is a Isolators - Gate Drivers manufactured by Renesas Electronics America Inc. HI-SPD OPTOCPLR 6PIN SDIP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - forward (vf) (typ) 1.56V, package / case 8-SOIC (0.268", 6.80mm Width).

Datasheet Request a Quote

In Stock: 4,831

Tiered Pricing USD
1+ $4.8000 —
10+ $3.5680 -26%
100+ $2.8388 -41%
500+ $2.5198 -48%
1,000+ $2.5092 -48% BEST

Specifications

18 parameters
Product StatusActive
TechnologyOptical Coupling
Number of Channels1
Voltage - Isolation5000Vrms
Common Mode Transient Immunity (Min)50kV/µs
Propagation Delay tpLH / tpHL (Max)200ns, 200ns
Pulse Width Distortion (Max)75ns
Rise / Fall Time (Typ)17ns, 17ns
Current - Output High, Low1.5A, 1.5A
Current - Peak Output2A
Voltage - Forward (Vf) (Typ)1.56V
Current - DC Forward (If) (Max)25 mA
Voltage - Output Supply15V ~ 30V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case8-SOIC (0.268", 6.80mm Width)
Supplier Device Package8-SOIC
Approval AgencyCSA, SEMKO, UL, VDE
