Name: PS9332L-E3-AX
Brand: Renesas Electronics America Inc
SKU: PS9332L-E3-AX
Price: 4.78 USD
Availability: InStock

REF: PS9332L-E3-AX Renesas Electronics America Inc

PS9332L-E3-AX

Renesas Electronics America Inc

HI-SPD OPTOCPLR 6PIN SDIP

PS9332L-E3-AX is a Isolators - Gate Drivers manufactured by Renesas Electronics America Inc. HI-SPD OPTOCPLR 6PIN SDIP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - forward (vf) (typ) 1.56V, package / case 8-SOIC (0.268", 6.80mm Width).

Datasheet Request a Quote

In Stock: 1,640

Tiered Pricing USD

1+ $4.7800 —

10+ $3.5490 -26%

100+ $2.8234 -41%

500+ $2.5057 -48%

1,000+ $2.4939 -48% BEST

Specifications

18 parameters

Product Status	Active
Technology	Optical Coupling
Number of Channels	1
Voltage - Isolation	5000Vrms
Common Mode Transient Immunity (Min)	50kV/µs
Propagation Delay tpLH / tpHL (Max)	200ns, 200ns
Pulse Width Distortion (Max)	75ns
Rise / Fall Time (Typ)	17ns, 17ns
Current - Output High, Low	1.5A, 1.5A

Current - Peak Output	2A
Voltage - Forward (Vf) (Typ)	1.56V
Current - DC Forward (If) (Max)	25 mA
Voltage - Output Supply	15V ~ 30V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.268", 6.80mm Width)
Supplier Device Package	8-SOIC
Approval Agency	CSA, SEMKO, UL, VDE
