Name: M38507F8ASP#U1
Brand: Renesas Electronics America Inc
SKU: M38507F8ASP#U1
Availability: InStock

REF: M38507F8ASP#U1 Renesas Electronics America Inc

M38507F8ASP#U1

IC MCU 8BIT 32KB FLASH 42SDIP

M38507F8ASP#U1 is a Embedded - Microcontrollers manufactured by Renesas Electronics America Inc. IC MCU 8BIT 32KB FLASH 42SDIP. Key specifications: mounting type Through Hole, operating temperature -20°C ~ 85°C (TA), voltage - supply (vcc/vdd) 1.8V ~ 5.5V, package / case 42-SDIP (0.600", 15.24mm).

Request a Quote

In Stock: 9,455

Specifications

18 parameters

Product Status	Obsolete
Core Processor	740
Core Size	8-Bit
Speed	12.5MHz
Connectivity	SIO, UART/USART
Peripherals	PWM, WDT
Number of I/O	32
Program Memory Size	32KB (32K x 8)
Program Memory Type	FLASH

EEPROM Size	-
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	1.8V ~ 5.5V
Data Converters	A/D 9x10b
Oscillator Type	Internal
Operating Temperature	-20°C ~ 85°C (TA)
Mounting Type	Through Hole
Package / Case	42-SDIP (0.600", 15.24mm)
Supplier Device Package	42-SDIP
