R570412100

In Stock: 31
R570412100 - Radiall USA, Inc. - RF Switches
REF: R570412100 Radiall USA, Inc.
R570412100

Radiall USA, Inc.

SP2 R S18 F 12 TL D P

R570412100 is a RF Switches manufactured by Radiall USA, Inc.. SP2 R S18 F 12 TL D P. Key specifications: operating temperature -40°C ~ 85°C, voltage - supply 10.2V ~ 13V, package / case Module, SMA Connectors, frequency range 0Hz ~ 18GHz.

Datasheet Request a Quote

In Stock: 31

Specifications

16 parameters
Product StatusActive
RF TypeGeneral Purpose
Topology-
CircuitSPDT
Frequency Range0Hz ~ 18GHz
Isolation60dB (min)
Insertion Loss0.35dB (max)
Test Frequency18GHz
P1dB-
IIP3-
Features-
Impedance50Ohm
Voltage - Supply10.2V ~ 13V
Operating Temperature-40°C ~ 85°C
Package / CaseModule, SMA Connectors
Supplier Device PackageModule
