R570013005

In Stock: 2
R570013005 - Radiall USA, Inc. - RF Switches
REF: R570013005 Radiall USA, Inc.
R570013005

Radiall USA, Inc.

SPDT RAMSES N 3GHZ FAILSAFE 28VD

R570013005 is a RF Switches manufactured by Radiall USA, Inc.. SPDT RAMSES N 3GHZ FAILSAFE 28VD. Key specifications: operating temperature -40°C ~ 85°C, voltage - supply 24V ~ 30V, package / case Module, frequency range 0Hz ~ 3GHz.

Datasheet Request a Quote

In Stock: 2

Specifications

16 parameters
Product StatusActive
RF TypeGeneral Purpose
Topology-
CircuitSPDT
Frequency Range0Hz ~ 3GHz
Isolation75dB
Insertion Loss0.25dB
Test Frequency3GHz
P1dB-
IIP3-
Features-
Impedance50Ohm
Voltage - Supply24V ~ 30V
Operating Temperature-40°C ~ 85°C
Package / CaseModule
Supplier Device Package-
