TOP253MN

In Stock: 1,518
TOP253MN - Power Integrations - PMIC - AC DC Converters, Offline Switchers
REF: TOP253MN Power Integrations
TOP253MN

Power Integrations

IC OFFLINE SW FLYBACK 10CSDIP

TOP253MN is a PMIC - AC DC Converters, Offline Switchers manufactured by Power Integrations. IC OFFLINE SW FLYBACK 10CSDIP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 150°C (TJ), package / case 10-SDIP (0.300", 7.62mm), 9 Leads, power (watts) 25 W.

Datasheet Request a Quote

In Stock: 1,518

Specifications

16 parameters
Product StatusObsolete
Output IsolationIsolated
Internal Switch(s)Yes
Voltage - Breakdown700V
TopologyFlyback
Voltage - Start Up-
Voltage - Supply (Vcc/Vdd)-
Duty Cycle78%
Frequency - Switching66kHz
Power (Watts)25 W
Fault ProtectionCurrent Limiting, Over Temperature, Over Voltage
Control Features-
Operating Temperature-40°C ~ 150°C (TJ)
Package / Case10-SDIP (0.300", 7.62mm), 9 Leads
Supplier Device PackageSDIP-10C
Mounting TypeThrough Hole
