IGD515EI

In Stock: 8,409
IGD515EI - Power Integrations - PMIC - Gate Drivers
REF: IGD515EI Power Integrations
IGD515EI

Power Integrations

IC GATE DRVR HI/LOW SIDE MODULE

IGD515EI is a PMIC - Gate Drivers manufactured by Power Integrations. IC GATE DRVR HI/LOW SIDE MODULE. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C (TA), voltage - supply 12V ~ 16V, package / case Module.

Datasheet Request a Quote

In Stock: 8,409

Tiered Pricing USD
1+ $177.1900 —
10+ $150.6100 -15%
40+ $141.7500 -20% BEST

Specifications

15 parameters
Product StatusNot For New Designs
Driven ConfigurationHigh-Side or Low-Side
Channel TypeSingle
Number of Drivers1
Gate TypeIGBT, N-Channel, P-Channel MOSFET
Voltage - Supply12V ~ 16V
Logic Voltage - VIL, VIH0.9V, 3.8V
Current - Peak Output (Source, Sink)15A, 15A
Input Type-
High Side Voltage - Max (Bootstrap)-
Rise / Fall Time (Typ)40ns, 40ns
Operating Temperature-40°C ~ 85°C (TA)
Mounting TypeThrough Hole
Package / CaseModule
Supplier Device PackageModule
