SN74LS38D

In Stock: 42,824
SN74LS38D - onsemi - Logic - Gates and Inverters
REF: SN74LS38D onsemi
SN74LS38D

onsemi

IC GATE NAND OPEN 4CH 2IN 14SOIC

SN74LS38D is a Logic - Gates and Inverters manufactured by onsemi. IC GATE NAND OPEN 4CH 2IN 14SOIC. Key specifications: mounting type Surface Mount, operating temperature 0°C ~ 70°C, voltage - supply 4.75V ~ 5.25V, package / case 14-SOIC (0.154", 3.90mm Width).

Datasheet Request a Quote

In Stock: 42,824

Specifications

15 parameters
Product StatusObsolete
Logic TypeNAND Gate
Number of Circuits4
Number of Inputs2
FeaturesOpen Collector
Voltage - Supply4.75V ~ 5.25V
Current - Quiescent (Max)2 mA
Current - Output High, Low-, 24mA
Logic Level - Low0.8V
Logic Level - High2V
Max Propagation Delay @ V, Max CL32ns @ 5V, 45pF
Operating Temperature0°C ~ 70°C
Mounting TypeSurface Mount
Supplier Device Package14-SOIC
Package / Case14-SOIC (0.154", 3.90mm Width)
