SN74LS30D

In Stock: 13,823
SN74LS30D - onsemi - Logic - Gates and Inverters
REF: SN74LS30D onsemi
SN74LS30D

onsemi

IC GATE NAND 1CH 8-INP 14SOIC

SN74LS30D is a Logic - Gates and Inverters manufactured by onsemi. IC GATE NAND 1CH 8-INP 14SOIC. Key specifications: mounting type Surface Mount, operating temperature 0°C ~ 70°C, voltage - supply 4.75V ~ 5.25V, package / case 14-SOIC (0.154", 3.90mm Width).

Datasheet Request a Quote

In Stock: 13,823

Specifications

15 parameters
Product StatusObsolete
Logic TypeNAND Gate
Number of Circuits1
Number of Inputs8
Features-
Voltage - Supply4.75V ~ 5.25V
Current - Quiescent (Max)500 µA
Current - Output High, Low400µA, 8mA
Logic Level - Low0.8V
Logic Level - High2V
Max Propagation Delay @ V, Max CL20ns @ 5V, 15pF
Operating Temperature0°C ~ 70°C
Mounting TypeSurface Mount
Supplier Device Package14-SOIC
Package / Case14-SOIC (0.154", 3.90mm Width)
