MJE180PWD

In Stock: 8,693
MJE180PWD - onsemi - Transistors - Bipolar (BJT) - Single
REF: MJE180PWD onsemi
MJE180PWD

onsemi

TRANS NPN 40V 3A TO126

MJE180PWD is a Transistors - Bipolar (BJT) - Single manufactured by onsemi. TRANS NPN 40V 3A TO126. Key specifications: mounting type Through Hole, operating temperature 150°C (TJ), package / case TO-225AA, TO-126-3, current - collector (ic) (max) 3 A.

Datasheet Request a Quote

In Stock: 8,693

Specifications

13 parameters
Product StatusObsolete
Transistor TypeNPN
Current - Collector (Ic) (Max)3 A
Voltage - Collector Emitter Breakdown (Max)40 V
Vce Saturation (Max) @ Ib, Ic1.7V @ 600mA, 3A
Current - Collector Cutoff (Max)100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce50 @ 100mA, 1V
Power - Max1.5 W
Frequency - Transition50MHz
Operating Temperature150°C (TJ)
Mounting TypeThrough Hole
Package / CaseTO-225AA, TO-126-3
Supplier Device PackageTO-126
