Name: FDPF33N25TRDTU
Brand: onsemi
SKU: FDPF33N25TRDTU
Price: 2.07 USD
Availability: InStock

REF: FDPF33N25TRDTU onsemi

FDPF33N25TRDTU

MOSFET N-CHANNEL 250V TO220F

FDPF33N25TRDTU is a Transistors - FETs, MOSFETs - Single manufactured by onsemi. MOSFET N-CHANNEL 250V TO220F. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 150°C (TJ), package / case TO-220-3 Full Pack, Formed Leads.

Datasheet Request a Quote

In Stock: 448

Specifications

17 parameters

Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	250 V
Current - Continuous Drain (Id) @ 25°C	33A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	94mOhm @ 16.5A, 10V
Vgs(th) (Max) @ Id	5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	48 nC @ 10 V

Vgs (Max)	±30V
Input Capacitance (Ciss) (Max) @ Vds	2135 pF @ 25 V
FET Feature	-
Power Dissipation (Max)	37W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-220F (LG-Formed)
Package / Case	TO-220-3 Full Pack, Formed Leads
