Name: BSS138-T
Brand: onsemi
SKU: BSS138-T
Availability: InStock

REF: BSS138-T onsemi

BSS138-T

MOSFET N-CH 50V 220MA SOT23-3

BSS138-T is a Transistors - FETs, MOSFETs - Single manufactured by onsemi. MOSFET N-CH 50V 220MA SOT23-3. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case 4-XFBGA.

Datasheet Request a Quote

In Stock: 7,550

Specifications

17 parameters

Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	50 V
Current - Continuous Drain (Id) @ 25°C	220mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	3.5Ohm @ 220mA, 10V
Vgs(th) (Max) @ Id	1.5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	2.4 nC @ 10 V

Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	27 pF @ 25 V
FET Feature	-
Power Dissipation (Max)	360mW (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	EFCP1313-4CC-037
Package / Case	4-XFBGA
