Name: 4N38VM
Brand: onsemi
SKU: 4N38VM
Price: 0.86 USD
Availability: InStock

REF: 4N38VM onsemi

4N38VM

OPTOISO 4.17KV TRANS W/BASE 6DIP

4N38VM is a Optoisolators - Transistor, Photovoltaic Output manufactured by onsemi. OPTOISO 4.17KV TRANS W/BASE 6DIP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 100°C, voltage - forward (vf) (typ) 1.15V, package / case 6-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 1,949

Tiered Pricing USD

1+ $0.8600 —

10+ $0.5160 -40%

100+ $0.3444 -60%

500+ $0.2770 -68%

1,000+ $0.2563 -70%

2,000+ $0.2393 -72%

5,000+ $0.2215 -74%

10,000+ $0.2109 -75%

25,000+ $0.1996 -77% BEST

Specifications

18 parameters

Product Status	Active
Number of Channels	1
Voltage - Isolation	4170Vrms
Current Transfer Ratio (Min)	20% @ 10mA
Current Transfer Ratio (Max)	-
Turn On / Turn Off Time (Typ)	5µs, 5µs
Rise / Fall Time (Typ)	-
Input Type	DC
Output Type	Transistor with Base

Voltage - Output (Max)	80V
Current - Output / Channel	100mA
Voltage - Forward (Vf) (Typ)	1.15V
Current - DC Forward (If) (Max)	80 mA
Vce Saturation (Max)	1V
Operating Temperature	-40°C ~ 100°C
Mounting Type	Through Hole
Package / Case	6-DIP (0.300", 7.62mm)
Supplier Device Package	6-DIP
