2SD1685F

In Stock: 24,889
2SD1685F - onsemi - Transistors - Bipolar (BJT) - Single
REF: 2SD1685F onsemi
2SD1685F

onsemi

TRANS NPN 20V 5A TO126ML

2SD1685F is a Transistors - Bipolar (BJT) - Single manufactured by onsemi. TRANS NPN 20V 5A TO126ML. Key specifications: mounting type Through Hole, operating temperature 150°C (TJ), package / case TO-225AA, TO-126-3, current - collector (ic) (max) 5 A.

Datasheet Request a Quote

In Stock: 24,889

Specifications

13 parameters
Product StatusObsolete
Transistor TypeNPN
Current - Collector (Ic) (Max)5 A
Voltage - Collector Emitter Breakdown (Max)20 V
Vce Saturation (Max) @ Ib, Ic500mV @ 60mA, 3A
Current - Collector Cutoff (Max)100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce160 @ 500mA, 2V
Power - Max1.5 W
Frequency - Transition120MHz
Operating Temperature150°C (TJ)
Mounting TypeThrough Hole
Package / CaseTO-225AA, TO-126-3
Supplier Device PackageTO-126ML
