MC56F8157VVFE

In Stock: 7,688
MC56F8157VVFE - NXP USA Inc. - Embedded - Microcontrollers
REF: MC56F8157VVFE NXP USA Inc.
MC56F8157VVFE

NXP USA Inc.

IC MCU 16B 256KB FLASH 160MAPBGA

MC56F8157VVFE is a Embedded - Microcontrollers manufactured by NXP USA Inc.. IC MCU 16B 256KB FLASH 160MAPBGA. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C (TA), voltage - supply (vcc/vdd) 2.25V ~ 3.6V, package / case 160-BGA.

Request a Quote

In Stock: 7,688

Specifications

18 parameters
Product StatusObsolete
Core Processor56800E
Core Size16-Bit
Speed40MHz
ConnectivityEBI/EMI, SCI, SPI
PeripheralsPOR, PWM, WDT
Number of I/O76
Program Memory Size256KB (128K x 16)
Program Memory TypeFLASH
EEPROM Size-
RAM Size8K x 16
Voltage - Supply (Vcc/Vdd)2.25V ~ 3.6V
Data ConvertersA/D 16x12b
Oscillator TypeExternal
Operating Temperature-40°C ~ 105°C (TA)
Mounting TypeSurface Mount
Package / Case160-BGA
Supplier Device Package160-MAPBGA (15x15)
