DSP56F807VF80

In Stock: 7,752
DSP56F807VF80 - NXP USA Inc. - Embedded - Microcontrollers
REF: DSP56F807VF80 NXP USA Inc.
DSP56F807VF80

NXP USA Inc.

IC MCU 16B 120KB FLASH 160MAPBGA

DSP56F807VF80 is a Embedded - Microcontrollers manufactured by NXP USA Inc.. IC MCU 16B 120KB FLASH 160MAPBGA. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), voltage - supply (vcc/vdd) 3V ~ 3.6V, package / case 160-BGA.

Datasheet Request a Quote

In Stock: 7,752

Specifications

18 parameters
Product StatusObsolete
Core Processor56800
Core Size16-Bit
Speed80MHz
ConnectivityCANbus, EBI/EMI, SCI, SPI
PeripheralsPOR, PWM, WDT
Number of I/O32
Program Memory Size120KB (60K x 16)
Program Memory TypeFLASH
EEPROM Size-
RAM Size4K x 16
Voltage - Supply (Vcc/Vdd)3V ~ 3.6V
Data ConvertersA/D 16x12b
Oscillator TypeExternal
Operating Temperature-40°C ~ 85°C (TA)
Mounting TypeSurface Mount
Package / Case160-BGA
Supplier Device Package160-MAPBGA (15x15)
