Name: NJU77552RB1-TE1
Brand: Nisshinbo Micro Devices Inc.
SKU: NJU77552RB1-TE1
Price: 1.22 USD
Availability: InStock

REF: NJU77552RB1-TE1 Nisshinbo Micro Devices Inc.

NJU77552RB1-TE1

Nisshinbo Micro Devices Inc.

IC OPAMP GP 2 CIRCUIT 8TVSP

NJU77552RB1-TE1 is a Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps manufactured by Nisshinbo Micro Devices Inc.. IC OPAMP GP 2 CIRCUIT 8TVSP. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, package / case 8-VSSOP, 8-MSOP (0.110", 2.80mm Width), current - supply 50µA.

Datasheet Request a Quote

In Stock: 9,300

Specifications

17 parameters

Product Status	Active
Amplifier Type	General Purpose
Number of Circuits	2
Output Type	Rail-to-Rail
Slew Rate	0.8V/µs
Gain Bandwidth Product	1.7 MHz
-3db Bandwidth	-
Current - Input Bias	1 pA
Voltage - Input Offset	1 mV

Current - Supply	50µA
Current - Output / Channel	60 mA
Voltage - Supply Span (Min)	1.8 V
Voltage - Supply Span (Max)	5.5 V
Operating Temperature	-55°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	8-VSSOP, 8-MSOP (0.110", 2.80mm Width)
Supplier Device Package	8-TVSP
