LM5109ASD

In Stock: 3,004
LM5109ASD - National Semiconductor - PMIC - Gate Drivers
REF: LM5109ASD National Semiconductor
LM5109ASD

National Semiconductor

HALF BRIDGE BASED MOSFET DRIVER,

LM5109ASD is a PMIC - Gate Drivers manufactured by National Semiconductor. HALF BRIDGE BASED MOSFET DRIVER,. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), voltage - supply 8V ~ 14V, package / case 8-WDFN Exposed Pad.

Datasheet Request a Quote

In Stock: 3,004

Tiered Pricing USD
1,000+ $0.8698 —
2,000+ $0.8459 -3%
3,000+ $0.8339 -4%
5,000+ $0.8206 -6%
7,000+ $0.8128 -7%
10,000+ $0.8053 -7% BEST

Specifications

15 parameters
Product StatusActive
Driven ConfigurationHalf-Bridge
Channel TypeIndependent
Number of Drivers2
Gate TypeN-Channel MOSFET
Voltage - Supply8V ~ 14V
Logic Voltage - VIL, VIH0.8V, 2.2 V
Current - Peak Output (Source, Sink)1A, 1A
Input TypeNon-Inverting
High Side Voltage - Max (Bootstrap)108 V
Rise / Fall Time (Typ)15ns, 15ns
Operating Temperature-40°C ~ 125°C (TJ)
Mounting TypeSurface Mount
Package / Case8-WDFN Exposed Pad
Supplier Device Package8-WSON (4x4)
