LM309K STEEL

In Stock: 35
LM309K STEEL - National Semiconductor - PMIC - Voltage Regulators - Linear
REF: LM309K STEEL National Semiconductor
LM309K STEEL

National Semiconductor

IC REG LINEAR 5.05V 1.5A TO3-2

LM309K STEEL is a PMIC - Voltage Regulators - Linear manufactured by National Semiconductor. IC REG LINEAR 5.05V 1.5A TO3-2. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 125°C, package / case TO-204AA, TO-3, current - supply (max) 10 mA.

Datasheet Request a Quote

In Stock: 35

Specifications

18 parameters
Product StatusActive
Output ConfigurationPositive
Output TypeFixed
Number of Regulators1
Voltage - Input (Max)25V
Voltage - Output (Min/Fixed)5.05V
Voltage - Output (Max)-
Voltage Dropout (Max)-
Current - Output1.5A
Current - Quiescent (Iq)5.2 mA
Current - Supply (Max)10 mA
PSRR-
Control Features-
Protection FeaturesOver Temperature
Operating Temperature0°C ~ 125°C
Mounting TypeThrough Hole
Package / CaseTO-204AA, TO-3
Supplier Device PackageTO-3-2
