MP6539BGV-P

In Stock: 1,000
MP6539BGV-P - Monolithic Power Systems Inc. - PMIC - Gate Drivers
REF: MP6539BGV-P Monolithic Power Systems Inc.
MP6539BGV-P

Monolithic Power Systems Inc.

100V, THREE-PHASE BLDC MOTOR PRE

MP6539BGV-P is a PMIC - Gate Drivers manufactured by Monolithic Power Systems Inc.. 100V, THREE-PHASE BLDC MOTOR PRE. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), voltage - supply 8.5V ~ 14V, package / case 28-VFQFN Exposed Pad.

Datasheet Request a Quote

In Stock: 1,000

Tiered Pricing USD
1+ $2.9400 —
10+ $2.1950 -25%
25+ $2.0096 -32%
100+ $1.8061 -39%
250+ $1.7091 -42% BEST

Specifications

15 parameters
Product StatusActive
Driven ConfigurationHalf-Bridge
Channel Type3-Phase
Number of Drivers2
Gate TypeN-Channel MOSFET
Voltage - Supply8.5V ~ 14V
Logic Voltage - VIL, VIH0.8V, 2V
Current - Peak Output (Source, Sink)800mA, 1A
Input TypeNon-Inverting
High Side Voltage - Max (Bootstrap)100 V
Rise / Fall Time (Typ)-
Operating Temperature-40°C ~ 125°C (TJ)
Mounting TypeSurface Mount
Package / Case28-VFQFN Exposed Pad
Supplier Device Package28-QFN (4x5)
