MP1917AGR-Z

In Stock: 8,041
MP1917AGR-Z - Monolithic Power Systems Inc. - PMIC - Gate Drivers
REF: MP1917AGR-Z Monolithic Power Systems Inc.
MP1917AGR-Z

Monolithic Power Systems Inc.

100V, 4A, HIGH-FREQUENCY HALF-BR

MP1917AGR-Z is a PMIC - Gate Drivers manufactured by Monolithic Power Systems Inc.. 100V, 4A, HIGH-FREQUENCY HALF-BR. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), voltage - supply 8V ~ 15V, package / case 10-VDFN Exposed Pad.

Datasheet Request a Quote

In Stock: 8,041

Tiered Pricing USD
5,000+ $0.8446 —
10,000+ $0.8290 -2% BEST

Specifications

15 parameters
Product StatusActive
Driven ConfigurationHalf-Bridge
Channel TypeIndependent
Number of Drivers2
Gate TypeN-Channel MOSFET
Voltage - Supply8V ~ 15V
Logic Voltage - VIL, VIH1V, 2.4V
Current - Peak Output (Source, Sink)4A, 6A
Input TypeNon-Inverting
High Side Voltage - Max (Bootstrap)2 V
Rise / Fall Time (Typ)15ns, 15ns
Operating Temperature-40°C ~ 125°C (TJ)
Mounting TypeSurface Mount
Package / Case10-VDFN Exposed Pad
Supplier Device Package10-QFN (4x4)
