APTGT100DA170D1G

In Stock: 3,048
APTGT100DA170D1G - Microsemi Corporation - Transistors - IGBTs - Modules
REF: APTGT100DA170D1G Microsemi Corporation
APTGT100DA170D1G

Microsemi Corporation

IGBT MODULE 1700V 200A 695W D1

APTGT100DA170D1G is a Transistors - IGBTs - Modules manufactured by Microsemi Corporation. IGBT MODULE 1700V 200A 695W D1. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 150°C (TJ), package / case D1, current - collector (ic) (max) 200 A.

Datasheet Request a Quote

In Stock: 3,048

Specifications

15 parameters
Product StatusDiscontinued at Digi-Key
IGBT TypeTrench Field Stop
ConfigurationSingle
Voltage - Collector Emitter Breakdown (Max)1700 V
Current - Collector (Ic) (Max)200 A
Power - Max695 W
Vce(on) (Max) @ Vge, Ic2.4V @ 15V, 100A
Current - Collector Cutoff (Max)3 mA
Input Capacitance (Cies) @ Vce8.5 nF @ 25 V
InputStandard
NTC ThermistorNo
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeChassis Mount
Package / CaseD1
Supplier Device PackageD1
