APTGF300A120D3G

In Stock: 9,639
APTGF300A120D3G - Microsemi Corporation - Transistors - IGBTs - Modules
REF: APTGF300A120D3G Microsemi Corporation
APTGF300A120D3G

Microsemi Corporation

IGBT MODULE 1200V 420A 2100W D3

APTGF300A120D3G is a Transistors - IGBTs - Modules manufactured by Microsemi Corporation. IGBT MODULE 1200V 420A 2100W D3. Key specifications: mounting type Chassis Mount, package / case D-3 Module, current - collector (ic) (max) 420 A, power - max 2100 W.

Datasheet Request a Quote

In Stock: 9,639

Specifications

15 parameters
Product StatusObsolete
IGBT TypeNPT
ConfigurationHalf Bridge
Voltage - Collector Emitter Breakdown (Max)1200 V
Current - Collector (Ic) (Max)420 A
Power - Max2100 W
Vce(on) (Max) @ Vge, Ic3.7V @ 15V, 300A
Current - Collector Cutoff (Max)5 mA
Input Capacitance (Cies) @ Vce19 nF @ 25 V
InputStandard
NTC ThermistorNo
Operating Temperature-
Mounting TypeChassis Mount
Package / CaseD-3 Module
Supplier Device PackageD3
