Name: QJ8006NH4RP
Brand: Littelfuse Inc.
SKU: QJ8006NH4RP
Price: 5.23 USD
Availability: InStock

REF: QJ8006NH4RP Littelfuse Inc.

QJ8006NH4RP

TRIAC ALTERNISTOR 800V 6A TO263

QJ8006NH4RP is a Thyristors - TRIACs manufactured by Littelfuse Inc.. TRIAC ALTERNISTOR 800V 6A TO263. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 150°C (TJ), package / case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB.

Datasheet Request a Quote

In Stock: 493

Tiered Pricing USD

1+ $5.2300 —

10+ $3.4980 -33%

100+ $2.5155 -52% BEST

Specifications

13 parameters

Product Status	Active
Triac Type	Alternistor - Snubberless
Voltage - Off State	800 V
Current - On State (It (RMS)) (Max)	6 A
Voltage - Gate Trigger (Vgt) (Max)	1.3 V
Current - Non Rep. Surge 50, 60Hz (Itsm)	65A, 80A
Current - Gate Trigger (Igt) (Max)	35 mA

Current - Hold (Ih) (Max)	35 mA
Configuration	Single
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package	TO-263 (D²Pak)
