Name: Q8010NH2TP
Brand: Littelfuse Inc.
SKU: Q8010NH2TP
Price: 3.93 USD
Availability: InStock

REF: Q8010NH2TP Littelfuse Inc.

Q8010NH2TP

TRIAC ALTERNISTOR 800V 10A TO263

Q8010NH2TP is a Thyristors - TRIACs manufactured by Littelfuse Inc.. TRIAC ALTERNISTOR 800V 10A TO263. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), package / case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB.

Datasheet Request a Quote

In Stock: 684

Tiered Pricing USD

1+ $3.9300 —

50+ $2.0138 -49%

100+ $1.8289 -53%

500+ $1.5225 -61% BEST

Specifications

13 parameters

Product Status	Active
Triac Type	Alternistor - Snubberless
Voltage - Off State	800 V
Current - On State (It (RMS)) (Max)	10 A
Voltage - Gate Trigger (Vgt) (Max)	1.3 V
Current - Non Rep. Surge 50, 60Hz (Itsm)	110A, 120A
Current - Gate Trigger (Igt) (Max)	5 mA

Current - Hold (Ih) (Max)	10 mA
Configuration	Single
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package	TO-263 (D²Pak)
