Name: MAC4DCM-1G
Brand: Littelfuse Inc.
SKU: MAC4DCM-1G
Price: 0.65 USD
Availability: InStock

REF: MAC4DCM-1G Littelfuse Inc.

MAC4DCM-1G

TRIAC 600V 4A IPAK

MAC4DCM-1G is a Thyristors - TRIACs manufactured by Littelfuse Inc.. TRIAC 600V 4A IPAK. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), package / case TO-252-3, DPak (2 Leads + Tab), SC-63.

Datasheet Request a Quote

In Stock: 8,890

Specifications

13 parameters

Product Status	Active
Triac Type	Standard
Voltage - Off State	600 V
Current - On State (It (RMS)) (Max)	4 A
Voltage - Gate Trigger (Vgt) (Max)	1.3 V
Current - Non Rep. Surge 50, 60Hz (Itsm)	40A @ 60Hz
Current - Gate Trigger (Igt) (Max)	35 mA

Current - Hold (Ih) (Max)	35 mA
Configuration	Single
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package	TO-252, (D-Pak)
