Name: HQ6025NH5RP
Brand: Littelfuse Inc.
SKU: HQ6025NH5RP
Price: 4.89 USD
Availability: InStock

REF: HQ6025NH5RP Littelfuse Inc.

HQ6025NH5RP

TRIAC ALTERNISTOR 600V TO263AB

HQ6025NH5RP is a Thyristors - TRIACs manufactured by Littelfuse Inc.. TRIAC ALTERNISTOR 600V TO263AB. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C (TJ), package / case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB.

Datasheet Request a Quote

In Stock: 8,909

Tiered Pricing USD

1+ $4.8900 —

10+ $3.2610 -33%

100+ $2.3353 -52% BEST

Specifications

13 parameters

Product Status	Active
Triac Type	Alternistor - Snubberless
Voltage - Off State	600 V
Current - On State (It (RMS)) (Max)	25 A
Voltage - Gate Trigger (Vgt) (Max)	1.3 V
Current - Non Rep. Surge 50, 60Hz (Itsm)	250A, 300A
Current - Gate Trigger (Igt) (Max)	50 mA

Current - Hold (Ih) (Max)	80 mA
Configuration	Single
Operating Temperature	-40°C ~ 105°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package	TO-263AB
