Name: IT132 DIE
Brand: Linear Integrated Systems, Inc.
SKU: IT132 DIE
Price: 3.66 USD
Availability: InStock

REF: IT132 DIE Linear Integrated Systems, Inc.

IT132 DIE

Linear Integrated Systems, Inc.

TIGHTLY MATCHED, MONOLITHIC DUAL

IT132 DIE is a Transistors - Bipolar (BJT) - Arrays manufactured by Linear Integrated Systems, Inc.. TIGHTLY MATCHED, MONOLITHIC DUAL. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case Die, current - collector (ic) (max) 10mA.

Datasheet Request a Quote

In Stock: 7,241

Specifications

13 parameters

Product Status	Active
Transistor Type	2 PNP (Dual)
Current - Collector (Ic) (Max)	10mA
Voltage - Collector Emitter Breakdown (Max)	45V
Vce Saturation (Max) @ Ib, Ic	500mV @ 50µA, 500µA
Current - Collector Cutoff (Max)	1nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	100 @ 1mA, 5V

Power - Max	500mW
Frequency - Transition	90MHz
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	Die
Supplier Device Package	Die
