S123BD

In Stock: 8,416
S123BD - L3 Narda-MITEQ - RF Switches
REF: S123BD L3 Narda-MITEQ
S123BD

L3 Narda-MITEQ

3 WATT PIN SWITCH SP2T 2-18 GHZ

S123BD is a RF Switches manufactured by L3 Narda-MITEQ. 3 WATT PIN SWITCH SP2T 2-18 GHZ. Key specifications: operating temperature -54°C ~ 95°C, package / case Module, SMA Connectors, frequency range 2GHz ~ 18GHz, circuit SPDT.

Datasheet Request a Quote

In Stock: 8,416

Specifications

16 parameters
Product StatusActive
RF TypeGeneral Purpose
TopologyReflective
CircuitSPDT
Frequency Range2GHz ~ 18GHz
Isolation55dB (min)
Insertion Loss2.5dB (max)
Test Frequency12GHz ~ 18GHz
P1dB-
IIP3-
Features-
Impedance-
Voltage - Supply-
Operating Temperature-54°C ~ 95°C
Package / CaseModule, SMA Connectors
Supplier Device PackageModule
