MOC8102X

In Stock: 8,740
MOC8102X - Isocom Components 2004 LTD - Optoisolators - Transistor, Photovoltaic Output
REF: MOC8102X Isocom Components 2004 LTD
MOC8102X

Isocom Components 2004 LTD

OPTOISO 5.3KV TRANS 6DIP

MOC8102X is a Optoisolators - Transistor, Photovoltaic Output manufactured by Isocom Components 2004 LTD. OPTOISO 5.3KV TRANS 6DIP. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 100°C, voltage - forward (vf) (typ) 1.15V, package / case 6-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 8,740

Tiered Pricing USD
1+ $0.5900 —
65+ $0.3134 -47%
130+ $0.2866 -51%
520+ $0.2441 -59%
1,040+ $0.2275 -61%
2,015+ $0.2139 -64%
5,005+ $0.1984 -66%
10,010+ $0.1887 -68%
25,025+ $0.1781 -70% BEST

Specifications

18 parameters
Product StatusActive
Number of Channels1
Voltage - Isolation5300Vrms
Current Transfer Ratio (Min)73% @ 10mA
Current Transfer Ratio (Max)117% @ 10mA
Turn On / Turn Off Time (Typ)-
Rise / Fall Time (Typ)2µs, 2µs
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)30V
Current - Output / Channel50mA
Voltage - Forward (Vf) (Typ)1.15V
Current - DC Forward (If) (Max)60 mA
Vce Saturation (Max)400mV
Operating Temperature-55°C ~ 100°C
Mounting TypeThrough Hole
Package / Case6-DIP (0.300", 7.62mm)
Supplier Device Package6-DIP
