Name: MOC3012XSM
Brand: Isocom Components 2004 LTD
SKU: MOC3012XSM
Price: 0.35 USD
Availability: InStock

REF: MOC3012XSM Isocom Components 2004 LTD

MOC3012XSM

Isocom Components 2004 LTD

OPTOISOLATOR 5.3KV TRIAC 6SMD

MOC3012XSM is a Optoisolators - Triac, SCR Output manufactured by Isocom Components 2004 LTD. OPTOISOLATOR 5.3KV TRIAC 6SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 100°C, voltage - forward (vf) (typ) 1.2V, package / case 6-SMD, Gull Wing.

Datasheet Request a Quote

In Stock: 9,928

Specifications

18 parameters

Product Status	Active
Output Type	Triac
Zero Crossing Circuit	No
Number of Channels	1
Voltage - Isolation	5300Vrms
Voltage - Off State	250 V
Static dV/dt (Min)	10V/µs (Typ)
Current - LED Trigger (Ift) (Max)	5mA
Current - On State (It (RMS)) (Max)	-

Current - Hold (Ih)	100µA
Turn On Time	-
Voltage - Forward (Vf) (Typ)	1.2V
Current - DC Forward (If) (Max)	50 mA
Operating Temperature	-40°C ~ 100°C
Mounting Type	Surface Mount
Package / Case	6-SMD, Gull Wing
Supplier Device Package	-
Approval Agency	UR, VDE
