CNY17F-2X

In Stock: 9,972
CNY17F-2X - Isocom Components 2004 LTD - Optoisolators - Transistor, Photovoltaic Output
REF: CNY17F-2X Isocom Components 2004 LTD
CNY17F-2X

Isocom Components 2004 LTD

OPTOISO 5.3KV TRANSISTOR 6DIP

CNY17F-2X is a Optoisolators - Transistor, Photovoltaic Output manufactured by Isocom Components 2004 LTD. OPTOISO 5.3KV TRANSISTOR 6DIP. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 100°C, voltage - forward (vf) (typ) 1.2V, package / case 6-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 9,972

Specifications

18 parameters
Product StatusActive
Number of Channels1
Voltage - Isolation5300Vrms
Current Transfer Ratio (Min)63% @ 10mA
Current Transfer Ratio (Max)125% @ 10mA
Turn On / Turn Off Time (Typ)3µs, 2.3µs
Rise / Fall Time (Typ)2µs, 2µs
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)70V
Current - Output / Channel50mA
Voltage - Forward (Vf) (Typ)1.2V
Current - DC Forward (If) (Max)60 mA
Vce Saturation (Max)400mV
Operating Temperature-55°C ~ 100°C
Mounting TypeThrough Hole
Package / Case6-DIP (0.300", 7.62mm)
Supplier Device Package6-DIP
