Name: TLE42754D
Brand: Infineon Technologies
SKU: TLE42754D
Availability: InStock

REF: TLE42754D Infineon Technologies

TLE42754D

IC REG LINEAR VOLT TLE42754

TLE42754D is a PMIC - Voltage Regulators - Linear manufactured by Infineon Technologies. IC REG LINEAR VOLT TLE42754. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 150°C (TJ), package / case TO-252-5, DPak (4 Leads + Tab), TO-252AD, current - supply (max) 25 mA.

Datasheet Request a Quote

In Stock: 6,755

Specifications

18 parameters

Product Status	Active
Output Configuration	Positive
Output Type	Fixed
Number of Regulators	1
Voltage - Input (Max)	42V
Voltage - Output (Min/Fixed)	5V
Voltage - Output (Max)	-
Voltage Dropout (Max)	0.5V @ 300mA
Current - Output	450mA

Current - Quiescent (Iq)	220 µA
Current - Supply (Max)	25 mA
PSRR	60dB (100Hz)
Control Features	Reset
Protection Features	Over Current, Over Temperature, Reverse Polarity
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-252-5, DPak (4 Leads + Tab), TO-252AD
Supplier Device Package	PG-TO252-5
