Name: TLE42702AKSA1
Brand: Infineon Technologies
SKU: TLE42702AKSA1
Availability: InStock

REF: TLE42702AKSA1 Infineon Technologies

TLE42702AKSA1

IC REG LINEAR 5V 650MA TO220-5

TLE42702AKSA1 is a PMIC - Voltage Regulators - Linear manufactured by Infineon Technologies. IC REG LINEAR 5V 650MA TO220-5. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 150°C, package / case TO-220-5 Formed Leads, current - supply (max) 90 mA.

Datasheet Request a Quote

In Stock: 6,217

Specifications

18 parameters

Product Status	Obsolete
Output Configuration	Positive
Output Type	Fixed
Number of Regulators	1
Voltage - Input (Max)	42V
Voltage - Output (Min/Fixed)	5V
Voltage - Output (Max)	-
Voltage Dropout (Max)	0.7V @ 550mA
Current - Output	650mA

Current - Quiescent (Iq)	1.5 mA
Current - Supply (Max)	90 mA
PSRR	54dB (100Hz)
Control Features	Reset
Protection Features	Over Current, Over Temperature, Over Voltage, Reverse Polarity, Short Circuit, Transient Voltage
Operating Temperature	-40°C ~ 150°C
Mounting Type	Through Hole
Package / Case	TO-220-5 Formed Leads
Supplier Device Package	PG-TO220-5
